JCT-FN200/1037 =>XP설치가능

최종 수정일: 2019년 8월 9일



KC인증 MSIP-REM-JPW-JCT-FN200




CPU Intel Celeron 1037U Dual Core 1.8G CPU

ChipsetIntel NM70

RAM 1 x SO DDR3 Memory Slot, Max.8GB

BIOS AMI BIOS, ACPI supported electricity boot

Display Integrated Intel HD2500 graphics support LVDS, HDMI,

VGA synchronous and asynchronous dual display

Network 2 x Gigabit RTL 8111E 1000M LAN, supports RTL and PXE diskless boot

Audio Realtek ALC662 chip, Line-in, Line-out

I/O 8 x USB 2.0, (4 x USB 2.0 on the Front Panel)

10 x COM RS232

1 x HDMI

2 x VGA

2 x RJ45LAN

Storage 1 x 2.5" HDD

Expansion 3 x SATA

2 x MINI PCI-E

1 x MSATA support WiFi and SSD

WDT Support hardware reset (256 level,0~255 sec)

Power Supply AC110-240V TO DC12V 5A/7A power adapter

TempStorage Temperature: -20℃ — 80℃ Working Temperature: -20℃ — 60℃

Humidity 10% - 90% Non-Condensing

Dimension 234 x 200 x 64.5 mm

Weight 2.5kg

Support system Windows XP,Windows7, Windows8,Linux
